GoodWe 10 kW On‑Grid Inverter

GoodWe 10 kW On‑Grid Inverter

The GoodWe 10 kW On‑Grid Inverter is a strong choice for homes, small businesses, or small commercial setups that want to convert solar energy into clean grid electricity. It delivers stable three‑phase AC output (or single‑phase in some markets), supports a flexible solar array design with multi‑MPPT inputs, and runs with high efficiency to maximize solar yield. Built with a weather‑resistant enclosure, smart safety protections, and optional remote monitoring, it offers reliable, low‑maintenance performance for everyday solar use.

Full Specifications:

• Inverter Type: Grid‑tied (on‑grid) string inverter

• Rated AC Output Power: 10 kW

• Maximum DC Input Voltage: approx. 1,000–1,100 V

• MPPT Trackers: 2 independent MPPT inputs

• MPPT Operating Voltage Range: ~200–950 V (depending on solar array)

• Maximum DC Input Power: ~13–15 kW (depending on PV array design)

• Strings per MPPT: up to 2 strings per tracker (flexible layout)

• Max Input Current per MPPT: ~20–25 A

• AC Output Voltage: 400 V three‑phase, 3L/N/PE (or 230 V / 240 V single-phase depending on region)

• Output Frequency: 50 / 60 Hz (region dependent)

• Peak Conversion Efficiency: ~97.5% – 98.5%

• Power Factor: Adjustable, typically near 1.0

• Cooling Method: Fan-based active cooling

• Protection Features: Over-voltage protection, over-current protection, surge protection, anti‑islanding, insulation/ground monitoring, short‑circuit protection

• Enclosure / Ingress Protection: Weather-resistant (suitable for rooftop or sheltered outdoor installation)

• Operating Temperature Range: approx. –20 °C to +60 °C (depending on environment)

• Communication & Monitoring: Standard interfaces (RS485 / LAN), optional remote monitoring modules

• Recommended Use: Residential homes, small commercial buildings, rooftop solar systems, grid-tied installations with net-metering or export
